{"Relay Terminals:":"Solder","External Depth:":"32.1 mm","Coil Resistance:":"660 ohm","Contact Configuration:":"SPDT","Contact Material:":"Silver Alloy","External Width:":"27.7 mm","Nom Operating Power:":"900 mW","Coil Voltage VDC Nom:":"24 V","Contact Voltage DC Nom:":"28 V","Contact Voltage VDC:":"28 V","Contact Current:":"30 A","Coil Current:":"36 mA","External Height:":"20.1 mm","Product Range:":"G8P Series","Contact Voltage AC Nom:":"250 V","SVHC:":"To Be Advised","Contact Voltage VAC:":"277 V","Coil V...

{"Category":"Relays","Turn Off Voltage (Min)":"2.4 VDC","Relay Type":"General Purpose","Termination Style":"PC Pin","Operating Temperature":"-55\u00b0C ~ 105\u00b0C","Coil Resistance":"660 Ohms","Coil Current":"36mA","Turn On Voltage (Max)":"18 VDC","Coil Type":"Non Latching","Switching Voltage":"250VAC, 28VDC - Max","Coil Power":"900 mW","Datasheets":"G8P Series","Standard Package":"50","Other Related Documents":"How to Read Date Codes","Coil Voltage":"24VDC","Contact Form":"SPDT (1 Form C)","Operate Time"...

{"Category":"Relays","Turn Off Voltage (Min)":"4.8 VDC","Relay Type":"General Purpose","Termination Style":"PC Pin","Operating Temperature":"-55\u00b0C ~ 105\u00b0C","Coil Resistance":"2.48 kOhms","Coil Current":"19mA","Turn On Voltage (Max)":"36 VDC","Coil Type":"Non Latching","Switching Voltage":"250VAC, 28VDC - Max","Coil Power":"900 mW","Datasheets":"G8P Series","Standard Package":"50","Other Related Documents":"How to Read Date Codes","Coil Voltage":"48VDC","Contact Form":"SPDT (1 Form C)","Operate Tim...

{"Category":"Relays","Turn Off Voltage (Min)":"11 VDC","Relay Type":"General Purpose","Termination Style":"PC Pin","Operating Temperature":"-55\u00b0C ~ 105\u00b0C","Coil Resistance":"12.4 kOhms","Coil Current":"9mA","Turn On Voltage (Max)":"82.5 VDC","Coil Type":"Non Latching","Switching Voltage":"250VAC, 28VDC - Max","Coil Power":"900 mW","Datasheets":"G8P Series","Standard Package":"50","Other Related Documents":"How to Read Date Codes","Coil Voltage":"110VDC","Contact Form":"SPDT (1 Form C)","PCN Obsole...

{"Category":"Relays","Turn Off Voltage (Min)":"1.2 VDC","Relay Type":"General Purpose","Termination Style":"PC Pin","Catalog Drawings":"G8P Sealed Case G8P Sealed Case Circuit","Operating Temperature":"-55\u00b0C ~ 105\u00b0C","Coil Resistance":"155 Ohms","Coil Current":"77mA","Turn On Voltage (Max)":"9 VDC","Product Photos":"G8P-1A4P-DC(5,12,24)","Switching Voltage":"250VAC, 28VDC - Max","Coil Power":"900 mW","Product Training Modules":"Medical Solutions","Datasheets":"G8PT Series","Standard Package":"50",...

{"Factory Pack Quantity":"50","Coil Current":"77 mA","Product Category":"General Purpose Relays","Series":"G8PT","Contact Form":"SPDT (1 Form C)","Coil Voltage":"12 V","Product":"Power Relays","Contact Termination":"Solder Pin","Mounting Style":"Through Hole","Power Consumption":"900 mW","Contact Material":"Silver Alloy","Part # Aliases":"375716 376403 430105 BY DC12 G8P-1C4P G8P-1C4P-DC12-BY-OMI G8P1C4P12DC G8P1C4PDC12BYOMI G8P1C4PDC12BYOMZ G8P1C4PDC12NC G8PT6015G OMI","Coil Resistance":"155 Ohms","Type":"...

{"Relay Construction":"Non-Latching","Coil Suppression Diode":"No","Termination Style":"PC Pin","Push To Test Button":"No","Type":"Power Relay","Coil Voltage DC":"12V","Coil Resistance":"155 ohm","Coil Current":"77 mA","Contact Arrangement":"SPDT","Product Height (mm)":"20.1 mm","Product Depth (mm)":"27.7 mm","Voltage Rating (VAC)":"250 V","Dropout Volt":"1.2VDC","Contact Form":"1 Form C","Operating Temp Range":"-55C to 105C","Voltage Rating (VDC)":"28 V","Pin Count":"5","Mounting Style":"Through Hole","Rad...

{"Category":"Relays","Turn Off Voltage (Min)":"1.5 VDC","Relay Type":"General Purpose","Termination Style":"PC Pin","Operating Temperature":"-55\u00b0C ~ 105\u00b0C","Coil Resistance":"256 Ohms","Coil Current":"60mA","Turn On Voltage (Max)":"11.25 VDC","Coil Type":"Non Latching","Switching Voltage":"250VAC, 28VDC - Max","Coil Power":"900 mW","Datasheets":"G8P Series","Standard Package":"50","Other Related Documents":"How to Read Date Codes","Coil Voltage":"15VDC","Contact Form":"SPDT (1 Form C)","Operate Ti...

{"Category":"Relays","Turn Off Voltage (Min)":"1.8 VDC","Relay Type":"General Purpose","Termination Style":"PC Pin","Operating Temperature":"-55\u00b0C ~ 105\u00b0C","Coil Resistance":"380 Ohms","Coil Current":"50mA","Turn On Voltage (Max)":"13.5 VDC","Coil Type":"Non Latching","Switching Voltage":"250VAC, 28VDC - Max","Coil Power":"900 mW","Datasheets":"G8P Series","Standard Package":"50","Other Related Documents":"How to Read Date Codes","Coil Voltage":"18VDC","Contact Form":"SPDT (1 Form C)","Operate Tim...
